Chipset: AMD B450

Rozměrový formát: ATX Form Factor (30.5 cm x 24.4 cm)
Podpora pro procesory: AMD Ryzen™ 2nd Generation/Ryzen™ with Radeon™ Vega Graphics/Ryzen™ 1st Generation Processors
Patice procesoru AMD AM4

Pozice na paměti: 4 x DIMM, Dual Channel Memory Architecture
Podpora pro paměti: DDR4 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz
Max.velikost operační paměti: 64 GB
Podpora pro paměti typu: Non-ECC

Grafická karta:
*HDMI 2.0b maximální rozlišení 4096 x 2160 @ 60 Hz
*DisplayPort 1.2 maximální rozlišení 4096 x 2160 @ 60 Hz
Zvuková karta: ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
Síťová karta: Intel® I211-AT, 1 x Gigabit LAN Controller

Rozšiřující sloty:
*2 x PCIe 3.0/2.0 x16 (x16 or x8/x4)
*1 x PCIe 3.0/2.0 x16 (x8 mode)
*1 x PCIe 2.0 x16 (max at x4 mode)
*3 x PCIe 2.0 x1
RAID řadič: Raid 0, 1, 10

SATA:
*8 x SATA 6Gb/s port(s)
USB:
*AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation :
*3 x USB 3.1 Gen 1 port(s) (3 na zadním panelu, blue)
*AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation :
*1 x USB 3.1 Gen 1 port(s) (1 na zadním panelu, , Type-C)
*AMD B450 chipset :
*2 x USB 3.1 Gen 2 port(s) (2 na zadním panelu red)
*AMD B450 chipset :
*2 x USB 3.1 Gen 1 port(s)
*AMD B450 chipset :
*6 x USB 2.0 port(s) (2 na zadním panelu, , 4 at mid-board)

Interní porty:
*2 x Aura RGB Strip Headers
*1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
*2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
*1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
*1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
*1 x TPM header
*1 x COM port(s) connector(s)
*6 x SATA 6Gb/s connector(s)
*1 x CPU Fan connector(s)
*1 x CPU OPT Fan connector(s)
*3 x Chassis Fan connector(s)
*1 x AIO_PUMP connector
*1 x 24-pin EATX Power connector(s)
*1 x 8-pin EATX 12V Power connectors
*1 x Front panel audio connector(s) (AAFP)
*1 x System panel(s)
*1 x Thermal sensor connector(s)
*1 x Clear CMOS jumper(s)

Externí porty:
*1 x PS/2 keyboard/mouse combo port(s)
*1 x DisplayPort
*1 x HDMI
*1 x LAN (RJ45) port(s)
*2 x USB 3.1 Gen 2 (red)Type-A,
*4 x USB 3.1 Gen 1 (blue) ,
*2 x USB 2.0
*1 x Optical S/PDIF out
*5 x Audio jack(s)
