Chipset: AMD B450

Rozměrový formát: ATX Form Factor (305 mm x 244 mm)
Podpora pro procesory: 3rd/2nd/1st Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics Processors
Patice procesoru: AM4

Pozice na paměti: 4x DDR4 DIMM
Podpora pro paměti: 4400(O.C)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
Max.velikost operační paměti: 128 GB
Podpora pro paměti typu: DDR4
*Dual Channel Memory Architecture

Grafická karta:
*Integrated Graphics Processor (na základě procesoru)

Multi GPU: Supports AMD 3-Way CrossFireX™ Technology

Zvuková karta:
*ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A

Síťová karta:
*Intel® I211-AT 1Gb Ethernet

Rozšiřující sloty:
*3rd/2nd/1st Gen AMD Ryzen™ Processors
*2x PCIe 3.0 x16 (x16 or x8/x4)
*2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
*1x PCIe 3.0 x16 (x8 mode)
*AMD Athlon™ with Radeon™ Vega Graphics Processors
*1x PCIe 3.0 x16 (x4 mode)
*AMD B450 chipset
*1x PCIe 2.0 x16 (x4 mode)
*3x PCIe 2.0 x1

RAID řadič: 0, 1, 10

SATA:
*6x SATA 6Gb/s ports

M.2:
*1x M.2 Socket 1 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
*1x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)

USB:
*zadní USB porty ( celkem 8 )
*2x USB 3.2 Gen 2 port(s)(2 x Type-A)
*4x USB 3.2 Gen 1 port(s)(3 x Type-A +1 x USB Type-C®)
*2x USB 2.0 port(s)
*přední USB porty ( celkem 4 )
*2x USB 3.2 Gen 1 port(s)
*2x USB 2.0 port(s)

Interní porty:
*1x CPU Fan connector(s)
*1x CPU OPT Fan connector(s)
*3x Chassis Fan connector(s)
*1x AIO_PUMP connector
*1x Addressable RGB header
*1x AAFP connector
*2x Aura RGB Strip Header(s)
*1x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
*1x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
*1x M.2 Socket 1 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
*1x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
*1x TPM header
*1x COM port(s) connector(s)
*6x SATA 6Gb/s connector(s)
*1x 24-pin EATX Power connector(s)
*1x 8-pin ATX 12V Power connector(s)
*1x System panel(s)
*1x Thermal sensor connector(s)
*1x Clear CMOS jumper(s)

Externí porty:
*1x Intel® I211-AT 1Gb Ethernet
*1x PS/2 keyboard/mouse combo port(s)
*1x DisplayPort
*1x HDMI
*2x USB 3.2 Gen 2
*3x USB 3.2 Gen 1 Type-A
*1x USB 3.2 Gen 1 USB Type-C®
*2x USB 2.0
*1x Optical S/PDIF out
*5x Audio jack(s)
*1x BIOS FlashBack™ Button(s)

Obsah balení:
*User's manual
*4x SATA 6Gb/s cable(s)
*1x Supporting DVD
*1x ROG Strix stickers
*1x Cable ties pack(s)
*1x Extension Cable for RGB strips (80 cm)
*1x Extension cable for Addressable LED
*1x ROG Thank you card
*1x M.2 SSD screw package(s)
*1x M.2 Rubber Package(s)

BIOS: 256 Mb Flash ROM, UEFI AMI BIOS

Stránka výrobce: https://www.asus.com/Motherboards/ROG-STRIX-B450-F-GAMING-II
https://www.asus.com/microsite/motherboard/ASUS-motherboards-Win11-ready/
https://www.asus.com/support/FAQ/1046215
